System parameters

Processor

Dual-core, 1 GHz

Memory

512 MB

Flash

512 MB

Micro SD card (default: sd1)

None

Hard disk

Not supported

Dimensions and weight

Dimensions (H x W x D)

• With no mounting bracket installed: 44.5 mm x 390.0 mm x 232.5 mm (1.75 in. x 15.35 in. x 9.15 in.)

• With mounting brackets installed: 44.5 mm x 482.6 mm x 232.5 mm (1.75 in. x 19.00 in. x 9.15 in.)

Weight

2.9 kg (6.39 lb)

Power specifications

Rated input voltage range (AC)

100 V to 240 V, 50 Hz/60 Hz

Maximum input voltage range (AC)

90 V to 264 V, 47 Hz to 63 Hz

Maximum input current

0.8 A

Maximum output power

25 W

RPS power supply

Not supported

PoE power supply

Not supported

Power consumption (empty chassis)

Typical power consumption

14 W

Maximum power consumption

15 W

Heat dissipation

Fans

None

Airflow (facing the front panel)

None

Interface density

Management interfaces

1 (RJ45)

CON/AUX interfaces

1 (RJ45)

USB 2.0 interfaces

2

Service interfaces (standard configuration)

WAN interfaces: four GE electrical interfaces and one GE optical interface

LAN interfaces: eight GE electrical interfaces

Extended slots

2xSIC

Environment parameters

Operating temperature

0°C to 45°C (32°F to 113°F)

NOTE:

When the altitude is between 1800 m and 5000 m, the highest operating temperature reduces by 1°C every time the altitude increases by 220 m.

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Operating relative humidity

5% to 95%, noncondensing

Operating altitude

< 5000 m (16404.2 ft.)

Part number

02350JGL
