Huawei S6730S-S24X6Q-A Part#(02353AJX/02353AJX-001/02353AJX-003/02353AJX-004)

Description

Huawei S6730S-S24X6Q-A(24*10 gigabit sfp+ ports,6*40GE QSFP ports, and 1*600W AC power supply)

Detailed description

S6730S-S24X6Q-A 24*10GE 40GE optical L3 core switch

Huawei CloudEngine S6730-S series full-featured 10 GE switches are Huawei's new generaion fixed switches to provide 10GEdownlink ports as well as 40/100GE uplink ports.

Huawei CloudEngine S6730-S can be used to provide high-speed access for 10 Gbits access to high-density servers orfunction as a core/aggregation switch on a campus network to provide 40 Gbit/s rate. in addition, S6730-S provides a widevariety of services, comprehensive security policies, and various QoS features to help customers build scalable, manageablereliable, and secure campus and data center networks.

Item	Description
Memory (RAM)	4 GB
Flash	2 GB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF)	62.27 years
Availability	> 0.99999
Service port surge protection	N/A
Power supply surge protection	Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Dimensions (H x W x D)	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.4 in. x 17.6 in.)
Weight (with packaging)	9.84 kg (21.69 lb)
Stack ports	Any 10GE SFP+ ports (a maximum of 16 physical ports) Any 40GE QSFP+ ports (a maximum of 6 physical ports)
RTC	Supported
RPS	Not supported
PoE	Not supported
Rated voltage range	AC input: 100 V AC to 240 V AC, 50/60 Hz High-Voltage DC input: 240 V DC DC input: -48 V DC to -60 V DC
Maximum voltage range	AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz High-Voltage DC input: 190 V DC to 290 V DC DC input: -38.4 V DC to -72 V DC
Maximum power consumption (100% throughput, full speed of fans)	249 W
Typical power consumption (30% of traffic load, tested according to ATIS standard)	135 W
Operating temperature	-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F).
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Noise under normal temperature (27°C, sound power)	< 65 dB(A)
Relative humidity	5% to 95%, noncondensing
Operating altitude	0-5000 m (0-16404 ft.)
Certification	EMC certification Safety certification Manufacturing certification
Part number	02353AJX 02353AJX-001 02353AJX-003 02353AJX-004
